12MM CIRCULAR TERMINAL SOCKET TECHNOLOGY
MT-YP-3220
Quantity:
12MM CIRCULAR TERMINAL SOCKET TECHNOLOGY
Feature and Benefit
- Material: Copper alloy
- Specification:Φ1.5mm-16mm
- Surface treatment: Ag plating, Ni, plating, Au plating
- Rated curent: 200-800A
- Operating temperature: -40℃-120℃
- Processing: turnning, forming, cold heading, precision carving.assembly and other composite processes
- Low contactresistance
- Lower mating force
- Low voltage drop
- Compact design
- High current transfer density
- Self-cleaning effect during the mating process
- Excellent shock and vibration resistance
- Over 12000 mating cycles
- Stamping&molding technology with lower costs
Noimia contact pins are the perfect addition to all contact systems.
The importance of pins is often underestimated and little attention is paid to them.
However, the quality of the pin is crucial for a permanently reliable connection for vehicle charging and connector.
The electrical performance and service life of a contact system are always determined by both contact partners.
Only high-quality materials and surface coating technologies are therefore used for Noimia Pins
